Product Details
Place of Origin: China
Brand Name: Forward
Model Number: MR-Hummingbird
Payment & Shipping Terms
Minimum Order Quantity: 1 PACK
Packaging Details: Standard Packaging
Payment Terms: L/C, T/T
Supply Ability: 100 pcs/years
Takeoff Weight: |
249 G |
Dimensions: |
Folded: 140×90×50mm Unfolded: 264×310×50mm |
Wheelbase: |
231 Mm |
Max Ascent Speed/strong>: |
6m/s (sport), 4m/s (normal), 3m/s (stable) |
Max Level Flight Speed: |
4m/s (sport), 3m/s (normal), 2m/s (stable) |
Max Takeoff Altitude: |
4000m |
Max Flight Time (no Wind): |
28min |
Max Flight Distance (no Wind): |
16.8km |
Takeoff Weight: |
249 G |
Dimensions: |
Folded: 140×90×50mm Unfolded: 264×310×50mm |
Wheelbase: |
231 Mm |
Max Ascent Speed/strong>: |
6m/s (sport), 4m/s (normal), 3m/s (stable) |
Max Level Flight Speed: |
4m/s (sport), 3m/s (normal), 2m/s (stable) |
Max Takeoff Altitude: |
4000m |
Max Flight Time (no Wind): |
28min |
Max Flight Distance (no Wind): |
16.8km |
The MR-Hummingbird Nano features powerful aerial photography capabilities packed in a compact, foldable, palm-sized frame. Even weights only 249g, the EVO Nano's 1/2" CMOS sensor 48MP camera paired with an ultra-stable three-axis mechanical gimbal is capable of recording smooth cinematic 4K/30fps HDR video in challenging conditions. The frame has been engineered to withstand up to level 5 winds. And with its 28-min flight time, 6.2 miles (10km) transmission distance, the MR-Hummingbird mini drone give you the ability to fly farther and see clearer.
• ＜249g
• 4K/FPS Video
• 10km Video Transmission
• Obstacle Sensing in 3 Directions
• Level 5 Wind Resistance
• 28-Min Max Flight Time
Specifications MR-Hummingbird Multi Rotor UAV :
| Takeoff Weight (without Accessories) |
249g | |
| Dimensions (including blades) |
Folded: 140×90×50mm Unfolded: 264×310×50mm |
|
| Wheelbase | 231mm | |
| Max Ascent Speed/strong> | 6m/s (sport), 4m/s (normal), 3m/s (stable) | |
| Max Level Flight Speed | 4m/s (sport), 3m/s (normal), 2m/s (stable) | |
| Max Level Flight Speed (no wind, near sea level) |
13m/s (sport), 10m/s (normal), 5m/s (stable) | |
| Max Takeoff Altitude | 4000m | |
| Max Flight Time (no wind) | 28min | |
| Max Hovering Time (no wind) | 26min | |
| Max Flight Distance (no wind) | 16.8km | |
| Max Wind Resistance | Level 5 | |
| Max Tilt Angle | 33°(movement), 25°(normal), 25°(stable) | |
| Max Angular Velocity | 200°(movement), 120°(normal), 60°(stable) | |
| Operating Temperature | -10°C ~ 40°C | |
| Transmission Power (EIRP) | FCC:≤30dBm | |
| GNSS | GPS | |
| Hovering Accuracy | Vertical:±0.1m (when the visual positioning is active), ±0.5m (with GPS positioning); Horizontal:±0.3m (when the visual positioning is active), ±1.5m (with GPS positioning); |
|
| Built-in storage | No | |
| SD storage | Max. support 256GB(UHS-3 rating required) | |
| Gimbal | ||
| Stabilization | 3-axis | |
| Mechanical Range | Pitch: -125°~35° Roll: -34°~33° Yaw: -25°~25° |
|
| Controllable Range | Pitch: -90°~ 0° | |
| Max Control Speed (pitch) | 30°/s | |
| Angular Vibration Range | ±0.003° | |
| Perception System | ||
| Forward | Accurate measurement range:0.5~16m Effective sensing speed:<10m/s FOV:Horizontal<40°,Vertical<30° |
|
| Backward | Accurate measurement range:0.5~18m Effective sensing speed:<12m/s FOV:Horizontal<40°,Vertical<30° |
|
| Downward | Accurate measurement range:0.5~20m Visual hovering range:0.5~40m FOV:Horizontal<40°,Vertical<30° |
|
| Operating environment | Forward, backward: Surface with clear pattern and adequate lighting(lux> 15) Downward: Surface with clear pattern and adequate lighting(lux> 15); Detects diffuse reflective surfaces(>20%) (walls, trees, people, etc.) |
|
| Camera | ||
| MR-Hummingbird | MR-Hummingbird+ | |
| Sensor | CMOS:1/2 inch; Effective pixels:48M Pixel size:1.6μm*1.6μm(Bin2) |
CMOS:1/1.28 inch Effective pixels:50MP Pixel size: 2.44μm*2.44μm (Bin2) |
| Lens | FOV:84° Equivalent focal length:24mm Aperture:f/2.8 Focus range:1m ~ ∞ Focus mode: fixed focus |
FOV: 85° Equivalent focal length: 23mm Aperture: f/1.9 Focus range: 0.5m ~ ∞ Focus mode::PDAF+CDAF/MF |
| Shooting mode | Automatic mode (P gear): EV adjustable, ISO/Shutter automatic Manual mode (M gear): ISO/Shutter adjustable, EV not adjustable Shutter priority (S file): Shutter/EV adjustable, ISO automatic |
Automatic mode (P gear): EV adjustable, ISO/Shutter automatic Manual mode (M gear): ISO/Shutter adjustable, EV not adjustable Shutter priority (S file): Shutter/EV adjustable, ISO automatic |
| ISO range | Video:ISO100 ~ ISO3200 Photo:ISO100 ~ ISO3200 |
Video:ISO100 ~ ISO6400 Photo:ISO100 ~ ISO6400 |
| Shutter speed | Photo Mode:1/8000 ~ 8s Other:1/8000 ~ 1/frame rates |
Photo Mode:1/8000 ~ 8s Other:1/8000 ~ 1/frame rates |
| Portrait blur | Real-time image transmission portrait blur and photo portrait blur | Real-time image transmission portrait blur and photo portrait blur |
| Defog mode | Support | Support |
| Zoom Range | Digital zoom:1 ~ 16 times | Digital zoom:1 ~ 16 times |
| Photo format | JPG/ DNG/ JPG+DNG | JPG/ DNG/ JPG+DNG |
| Photo resolution | 48MP:8000x6000(4:3) 12MP(default):4000x3000(4:3) 4K:3840x2160(16:9) |
50MP:8192x6144(4:3) 12.5MP(default):4096x3072(4:3) 4K:3840x2160(16:9) |
| Photo shooting mode | Single shot Burst shooing: 3/5 Auto exposure bracketing(AEB): 3/5 shots Interval: 2s/3s/4s/5s (default)/6s/.../60s (DNG min 5s) HDR imaging: 3840x2160 |
Single shot Burst shooing: 3/5 Auto exposure bracketing(AEB): 3/5 shots Interval: 2s/3s/4s/5s (default)/6s/.../60s (DNG min 5s) HDR imaging: 3840x2160 |
| Video coding format | H265/H264 | H265/H264 |
| Video resolution | 3840x2160 p30/25/24 2720x1528 p30/25/24 1920x1080 p60/50/48/30/25/24 |
3840x2160 p30/25/24 2720x1528 p30/25/24 1920x1080 p60/50/48/30/25/24 |
| Max bitrate | 100Mbps | 100Mbps |
| Timelapse | Original image:3840*2160,JPG/DNG Video: 4K P25 |
Original image:3840*2160,JPG/DNG Video: 4K P25 |
| Panorama | Horizontal/Vertical/Wide-angle/Spherical Original image: 4000*3000, JPG/DNG |
Horizontal/Vertical/Wide-angle/Spherical Original image: 4096*3072, JPG/DNG |
| Supported file system | Fat32,exFat | Fat32,exFat |
| Video format | MP4/MOV | MP4/MOV |
| WIFI transfer | 20MB/s | 20MB/s |
| Remote controllor and image transmission | ||
| Operating frequency | 2.400-2.4835GHz 5.725-5.850GHz 5.150-5.250GHz |
|
| Backward | Accurate measurement range:0.5~18m Effective sensing speed:<12m/s FOV:Horizontal<40°,Vertical<30° |
|
| Max transmission distance (unobstructed, free of interference) |
FCC:10km | |
| Operating temperature | 0°C ~40°C | |
| Transmission power (EIRP) | FCC:≤30dBm | |
| Battery capacity | 3930mAh | |
| Max battery life | ~ 3.5h (when connected to a mobile phone) ~ 2.5h (when not connected to mobile phone) |
|
| Interface type | Type C | |
| Transmission system | Autel SkyLink | |
| Realtime transmission quality | Transmission distance<1km:2.7K 30fps Transmission distance>1km:720P 30fps |
|
| Transmission bitrate | 90Mbps | |
| Transmission delay | ≤200ms | |
| Adapter | ||
| Input | 100-240V/50-60HZ | |
| Output | 5V==3A,9V⎓==A,12V==2.5A | |
| Rated power | 30W | |
| Aircraft Battery | ||
| Capacity | 2250mAh | |
| Voltage | 7.7V | |
| Max charging voltage | 8.8V | |
| Battery Type | Li-Po 2S | |
| Energy | 17.32Wh | |
| Charging temperature | 5~45℃ | |
| Single battery charging time | 90min | |
| Max charging power | 30W | |
| App | ||
| Mobile App | Autel Sky | |
| Mobile system required | iOS 12.0 and above Android 8.0 and above |
|
