FWD-4.3 4.3mm F1.2 256×192@12μm LWIR Motorized Zoom Lens with 8-12 μm Wavelength for Thermal Imaging

  • FWD-4.3 4.3mm F1.2 256×192@12μm LWIR Motorized Zoom Lens with 8-12 μm Wavelength for Thermal Imaging
Place of Origin China
Brand Name Forward
Model Number FWD-4.3
Minimum Order Quantity 1
Delivery Time 5-8 work days
Payment Terms T/T
Supply Ability 10000/year
Product Details
Highlight

4.3mm F1.2 thermal imaging lens

,

motorized zoom lens for LWIR

,

thermal imaging lens with 8-12μm wavelength
Leave a Message
Product Description
FWD-4.3 4.3mm F1.2 256×192@12μm LWIR Motorized Zoom Lens with 8-12 μm Wavelength for Thermal Imaging
Product Overview

FWD-4.3 4.3mm F1.2 256×192@12μm LWIR Motorized Zoom Lens — Chalcogenide Series. This innovative Chalcogenide glass lens series serves as an advanced alternative to traditional Germanium lenses, operating within the 8-12 μm wavelength band. Featuring a motorized athermalized design, it ensures stable and precise focusing across extreme temperatures from -40°C to +80°C.

Key Applications

Ideal for thermal imaging cameras, optical sights, and high-end security surveillance systems requiring reliable performance in demanding environments.

Key Parameters
  • Operating Wavelength: 8-12 μm (Long-Wave Infrared)
  • Operating Temperature: -40°C to +80°C (Ensuring stable performance in extreme environments)
  • Key Applications: Thermal imaging cameras, optical sights, and high-end security surveillance systems
Technical Specifications
Parameter Value
EFL 4.3mm
Sensor 256×192/12μm
FNo 1.2
FOV(D×H×V) 40°×30.2°
Wavelength 8-12μm
Transmittance >92%
Focus Fixed-type
Focus distance 0.1m~∞
Sealing IP67
Operation Temperature -40~80℃
Weight 0.7±0.3g
Product Image
FWD-4.3 4.3mm F1.2 256×192@12μm LWIR Motorized Zoom Lens with 8-12 μm Wavelength for Thermal Imaging 0
