Aviation Parts EPM78V2-03R3-01R0R Non-Isolated DC/DC Converters
| Model Number | EPM78V2-03R3-01R0R |
|---|---|
| Minimum Order Quantity | 1 pcs |
| Price | Negotiable |
| Packaging Details | boxes |
| Payment Terms | L/C, T/T |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Mfr | Eaton | Length | 11.61 Mm |
|---|---|---|---|
| Width | 10.21 Mm | Height | 7.62 Mm |
| Maximum Operating Temperature | + 90 C | Minimum Operating Temperature | - 40 C |
| Mounting Style | SMD/SMT | Output Voltage-Channel 1 | 3.3 V |
Product Description
Aviation Parts EPM78V2-03R3-01R0R Non-Isolated DC/DC Converters
Descriptions of Aviation Parts:
Eaton EPM78V Non-Isolated DC-DC Converters come in a 3-pin SIP package that is compatible with LM78 linear regulators. Eaton EPM78V DC-DC Converters feature a 4.75VDC to 32VDC input voltage range and output voltages from 1.8V to 15V at 1A output current. The series offers efficiency up to 96% and operates over a -40°C to +90°C temperature range. Eaton EPM78V Non-Isolated DC-DC Converters are ideal for use in a variety of industrial, energy, medical, and telecommunications applications.
Features of Aviation Parts:
• Switching regulator, Non-isolated DC-DC converter
• Convenient 3-Pin SIP Package compatible with LM78xx linear regulator
• Input voltages: 4.75 V to 32 Vdc
• 6 SKU’s representing 6 output voltages (1.8 V – 15 V) @ 1A output current
• Efficiency up to 96%
• Operating ambient temperature -40 °C to +90 °C
• Continuous short circuit protection
• EN62368 safety approval
Specifications of Aviation Parts:
| Description | Product Attribute |
| Manufacturer | Eaton |
| Length | 11.61 mm |
| Width | 10.21 mm |
| Height | 7.62 mm |
| Category | Power |
| Maximum Operating Temperature | + 90 C |
| Minimum Operating Temperature | - 40 C |
| Mounting Style | SMD/SMT |
| Number of Outputs | 1 Output |
| Output Current-Channel 1 | 1 A |
| Output Voltage-Channel 1 | 3.3 V |
| Packaging | Tube |
| Product | Non-Isolated / POL |
| Product Type | Non-Isolated DC-DC Converters |
| Series | EPM78 |
