Aviation Parts CXN3506 Cable Dieletric withstanding voltage ≧750V

Product Details

Model Number: CXN3506

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiable

Packaging Details: boxes

Payment Terms: L/C, T/T

Get Best Price
Highlight:
Frequency Range:
DC-50GHZ
Dieletric Withstanding Voltage:
≧750V
Characteristic Impedance:
50Ω
Insulation Resistance:
≧3000MΩ
VSWR:
1.3:1
Durability (matings):
≧500
Temperature Range:
-45℃ To 125℃
Connector Parts:
Plating
Pitch:
0.100" (2.54mm)
Tightening Torque Of Connection:
0.79-1.13N .m
Frequency Range:
DC-50GHZ
Dieletric Withstanding Voltage:
≧750V
Characteristic Impedance:
50Ω
Insulation Resistance:
≧3000MΩ
VSWR:
1.3:1
Durability (matings):
≧500
Temperature Range:
-45℃ To 125℃
Connector Parts:
Plating
Pitch:
0.100" (2.54mm)
Tightening Torque Of Connection:
0.79-1.13N .m
Aviation Parts CXN3506 Cable Dieletric withstanding voltage ≧750V

Aviation Parts CXN3506 Cable Dieletric withstanding voltage ≧750V





Descriptions of Aviation Parts:



Gore cables and cable assemblies incorporate the latest materials science to meet rigorous electrical, mechanical, and environmental requirements. Our cables are engineered for the most demanding applications to offer the highest-in-class performance. They are valued in multiple industries for delivering signal integrity, speed, and mechanical robustness in the harshest environments.



Features of Aviation Parts:

  • 0-26.5 Ghz
  • Standard brass, non-magnetic brass and stainless steel material options
  • Patented High Frequency and Self Fixture end launch connectors
  • Quick connect cable plugs and adapter

Specifications of Aviation Parts:





Electrical Characteristics
Impedance 50Ω
Frequency Range Connect with solf cable DC~12.4GHz
Connect with semi-rigid cable DC~18GHz
Rated Voltage 335VRMS
Dielectrics Voltage-resistance 1000VRMS
Insulation Resistance ≥5000MΩ
Center Resistance Center Conductor ≤3.0mΩ
Outer Conductor ≤2.0mΩ
VSWR ≤1.3
Material & Mechanical Characteristics
Center Conductor Male Brass Gold plated
Female Sn-P Bronze Gold plated
Elastic Contact Beryllium bronze Nickel plated
Shell and other Metal Parts Brass Nickel plated
Stainless Passivation
Crimping Sleeve Brass Nickel plated
Insulators PTFE
Sealing Ring Silicone Rubber
Durability 500 cycles
Tightening torque of connection 0.79-1.13N .m






Aviation Parts CXN3506 Cable Dieletric withstanding voltage ≧750V 0
