Aviation Parts 700-001-15 Circuit Breakers Acceleration Exceeds 10G’s

Product Details

Brand Name: Hawker Beechcraft

Model Number: 700-001-15

Payment & Shipping Terms

Price: Negotiable

Packaging Details: boxes

Payment Terms: L/C, T/T

Get Best Price
Highlight:
Interrupting Capacity:
6,000A At 30V, DC. 3,500A At 120V, 400 Hz., AC
Endurance:
At 120V, 400 Hz., AC Or 30V, DC: Inductive Load — 2,500 Cycles; Resistive Load — 5,000 Cycles; Mechanical Cycling, No Load — 5,000 Cycles
Overload Cycling:
100 Operations At 200% Rated Current And Rated Voltage
Dielectric Strength:
At Sea Level, 25°C 1,500V, AC. At 65,000 Ft., 70°C 500V, AC. 1,500V, Minimum
Insulation Resistance:
Not Less Than 100 Megohms At 500V, DC
Voltage Drop:
Varies With Rating (see “Ordering Information”)
Vibration:
Exceeds MIL-STD-202, Method 204, Condition A (Random Optional)
Acceleration:
Exceeds 10G’s
Interrupting Capacity:
6,000A At 30V, DC. 3,500A At 120V, 400 Hz., AC
Endurance:
At 120V, 400 Hz., AC Or 30V, DC: Inductive Load — 2,500 Cycles; Resistive Load — 5,000 Cycles; Mechanical Cycling, No Load — 5,000 Cycles
Overload Cycling:
100 Operations At 200% Rated Current And Rated Voltage
Dielectric Strength:
At Sea Level, 25°C 1,500V, AC. At 65,000 Ft., 70°C 500V, AC. 1,500V, Minimum
Insulation Resistance:
Not Less Than 100 Megohms At 500V, DC
Voltage Drop:
Varies With Rating (see “Ordering Information”)
Vibration:
Exceeds MIL-STD-202, Method 204, Condition A (Random Optional)
Acceleration:
Exceeds 10G’s
Aviation Parts 700-001-15 Circuit Breakers Acceleration Exceeds 10G’s

Aviation Parts 700-001-15 Circuit Breakers Acceleration Exceeds 10G’s







Descriptions of Aviation Parts:



Exceeds military specification requirements for durability, vibration, mechanical shock, and acceleration.The 700 is a miniature push-pull breaker offering fast trip and high interrupting capacity. Its trip-free design prevents the breaker from being held closed manually on overloads.

A feature of the breaker is separate overload and mechanical latches. Separated in this way, the mechanical latch assures maximum endurance for the thousands of cycles of manual on-off operation, while the thermal latch combines both precise operation and durability.



Features of Aviation Parts:



Qualified To MS25244, MS25244-P and MS25244-PT of MIL-C-5809 (MS25244PT is a substitute for MS25017) .

Lightweight

Circuit breaker weighs only 43 grams.

High Interrupting Capacity

Interrupts a 6,000A circuit at 30V, DC; 3,500A circuit at 120V, 400 Hz. AC



Specifications of Aviation Parts:
