Weight ≤16000g Electro Optical Pod Eagle-Eye16000 Heading NX360°

Product Details

Place of Origin: China

Brand Name: Forward

Model Number: Eagle-eye16000 Electro Optical Pod

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiable

Packaging Details: boxes

Delivery Time: 5-8 weeks

Payment Terms: L/C, T/T

Supply Ability: 500 pcs/years

Get Best Price
Highlight:

16000g Electro Optical Pod

,

NX360° Electro Optical Pod

,

Optical uav pod

Type:
Gyrostabilization
Weight:
≤16000g
Heading:
NX360°
Pitch:
+20°~-110°
Angular Position Accuracy:
≤ 35μrad(RMS)
Dimensions:
φ280mm×405.5mm
Operating Temperature:
-40℃~+55℃
Laser Ranging:
50~6000m
Type:
Gyrostabilization
Weight:
≤16000g
Heading:
NX360°
Pitch:
+20°~-110°
Angular Position Accuracy:
≤ 35μrad(RMS)
Dimensions:
φ280mm×405.5mm
Operating Temperature:
-40℃~+55℃
Laser Ranging:
50~6000m
Weight ≤16000g Electro Optical Pod Eagle-Eye16000 Heading NX360°

Electro Optical Pod Eagle-eye16000 Weight ≤16000g Heading NX360°





Descriptions of Electro Optical Pod:



Eagle-eye16000 electro optical pod is equipped with visible light TV, cooling infrared thermal imager and laser range finder. It has the characteristics of good stability, good observation effect, general purpose and high reliability. It can be used to perform tasks such as target search, capture, identification and tracking, and is suitable for various aircraft and vehicle platforms.



Features of Electro Optical Pod:

  • High-precision boresight stabilization function;
  • Has visible light and infrared reconnaissance functions;²
  • With laser ranging function;²
  • Visible light TV has functions such as optical continuous zoom, automatic focus and image enhancement;²
  • The thermal imager has the functions of optical continuous zoom, automatic focus, polarity conversion, non-uniformity correction and image enhancement;²
  • With manual mode, lock mode, scan mode and automatic tracking modes;²
  • Multi-target detection and prompt function;²
  • It has the function of completing target positioning and geographic guidance according to the carrier information;²
  • With high-definition image recording, ground data transfer function.²



Specifications of Electro Optical Pod:



Specification

Type: Gyro Stabilized

Weight: ≤16kg

Dimensions: φ280mm×405.5mm

Infrared Thermal Imaging

Detector Refrigerated medium wave HgCdTe (mercury cadmium telluride)

Resolution 640×512

Working band 3μm ~ 5μm

Field of view 2.2°×1.76°~22°×17.6°

Detection distance: ≥8km,

Recognition distance: ≥5km

Features

Two axes (pitch axis: +20°~-110°;

Heading axis: NX360°;

Stable accuracy: ≤ 35μrad(RMS)

Angle measurement accuracy ≤1mrad

Visible Light Imaging

Resolution 1920×1080

Working band 0.4µm~0.7µm

FOV 2°×1.12°~52.5°× 29.4°

Detection distance: ≥10km

Recognition distance: ≥7km

Laser Ranging


Working wavelength 1.54μm

Ranging range 50m~10000m

Ranging accuracy ≤2m

Tracking module

Tracking accuracy ≤0.1mrad (RMS)

Maximum search angular velocity ≥60°/s

Maximum tracking angular velocity ≥10°/s

External interface

Control interface :

2 way RS422 serial port

Video output :

1 channel network digital video output

1 synchronous 422 video output

1 channel HD-SDI video output

Power supply

Voltage: 28 VDC,

Power consumption: ≤200W (average),

≤300W (peak)

Environmental conditions

Working temperature -40℃~+60℃

Storage temperature - 50℃~+70℃
