FW-L50 Thermal Imaging PTZ Camera System Hunt Monocular Night Vision Outdoor Handheld

Product Details

Place of Origin: China

Brand Name: Forward

Model Number: FW-L50

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: boxes

Delivery Time: 1-2 weeks

Payment Terms: L/C, T/T

Supply Ability: 100 pcs/years

Get Best Price
Highlight:

Thermal Imaging Camera Night Vision

,

Night Vision PTZ Camera System

,

Outdoor Handheld PTZ Camera System

FW-L50 Thermal Imaging PTZ Camera System Hunt Monocular Night Vision Outdoor Handheld

FW-L50 New Thermal Imaging Camera Hunt Monocular Night Vision





Descriptions of New Thermal Imaging Camera Hunt Monocular Night Vision:



This series is a high-performance civil infrared thermal imager, which uses imported high-performance 384×288/640 × 480 high-resolution and high-sensitivity polysili condetector with excellent imaging effect.Compact design, compact size, dust-proof waterproof,with high-strength impact resistance, cold, heat, strong and durable, suitable for all kinds of environ- ments.





Performances of New Thermal Imaging Camera Hunt Monocular Night Vision:



>High resolution imported 384×288/640 ×480, 17μm high sensitivity polysilicon detector
>No film design, the highest frame frequency 50Hz, smooth picture without a catenary
>0.5 inch 1024×768 OLED display with fine picture quality
>Aluminum-magnesium Alloy CNC technology to produce one-piece m- olding body, excellent anti-shock performance, strong environmental adaptability
>Support rich image adjustment function, support menu function
>35/50 mm large Lens, long detection distance, high base magnification
>Integrated Range accuracy is higher, once calibration, life-long adjustment free

>Various types of clamps are optional, suitable for all kinds of main- stream guide rail

>Can replace 16340 battery, Standard Charger, long endurance

>Application area:Outdoor adventure, Emergency Rescue, Police enforcement, Personal security



FW-L50 Thermal Imaging PTZ Camera System Hunt Monocular Night Vision Outdoor Handheld 0

Specifications of New Thermal Imaging Camera Hunt Monocular Night Vision:





Model L35 L35M L50 L50M
Detector
Detector Type Imported high performance polysilicon detector
Spectral 8~14μm
Resolution 384×288 640×480
Frame Rate 50HZ
Pixel size 17μm
Lens
Focal length 35mm 50mm
FOV 10.6°×8.0° 12.4°×9.3°
Digital Zoom 2.0倍 2.2倍
Focusing Manual Focus
Display
Screen 1024×768,Color 0.39 inch OLED screen,
Video output format PAL

External Video

FW-L50 Thermal Imaging PTZ Camera System Hunt Monocular Night Vision Outdoor Handheld 1Image parameter

Correction Mode

Support



Non-stop correction

Luminance Support
Contrast ratio Support
Noise reduction Support
Electron amplification ×2,×4
Pseudo-color mode White Heat, sky, edge, black heat, red heat pseudo-color, iron red pseudo-color
Laser ranging None Up to 800m None Up to 800m
Start-up drawing time <5S
Cross cursor ≥5
Other functions Picture-in-picture, Pitch Angle, electronic compass, Tilt Angle, hot-spot tracking
Power System
Batteries Two 16340 batteries, rechargeable, with customized plug-in rechargeable treasure
Environmental adaptability
Operating temperature -40℃~60℃,<90%RH
Storage temperature -50℃-70℃
Dust/water proof IP67
Physical characteristics
Weight 480g 650g 480g 650g
Dimensions 220mm×85mm
Packaging content
Standard fitting (mainframe, guideway,custom external charging cable, video cable, sling, mirror cloth, brush,hexagon wrench, protective bag) × 1,16340 batteries × 2




FW-L50 Thermal Imaging PTZ Camera System Hunt Monocular Night Vision Outdoor Handheld 2
