MR-Max Series Multi Rotor Uav Aircraft Foldable

Product Details

Place of Origin: China

Brand Name: Forward

Model Number: MR-Max series

Payment & Shipping Terms

Minimum Order Quantity: 1 PACK

Packaging Details: Standard Packaging

Payment Terms: L/C, T/T

Supply Ability: 100 pcs/years

Get Best Price
Highlight:

Multi Rotor uav aircraft

,

foldable uav aircraft

Takeoff Weight:
MR-Max 4T 1620g;MR-Max 4N 1641g
Wheelbase:
466mm
Size (L*W*H):
562*651*147 (folded, Incl. Propellers) 318*400*147(folded, Excl. Propellers) 257*145*131 (unfolded, Excl. Propellers)
Max Flight Time (No Wind):
42min
IP Rating:
IP43
Operating Temperature:
-20-50°C
Takeoff Weight:
MR-Max 4T 1620g;MR-Max 4N 1641g
Wheelbase:
466mm
Size (L*W*H):
562*651*147 (folded, Incl. Propellers) 318*400*147(folded, Excl. Propellers) 257*145*131 (unfolded, Excl. Propellers)
Max Flight Time (No Wind):
42min
IP Rating:
IP43
Operating Temperature:
-20-50°C
MR-Max Series Multi Rotor Uav Aircraft Foldable

MR-Max series Multi Rotor UAV

Description:



The MR-Max series brings you advanced autonomy. It assesses complex environments to create real-time 3D flight paths for unparalleled obstacle avoidance. Advanced sensors make flight in GPS unavailable areas possible and the incredible thermal and starlight cameras unlock new object identification and tracking scenarios. With a foldable, weather-resistant design, the series is as portable as it is capable.

MR-Max Series Multi Rotor Uav Aircraft Foldable 0

Feature:

  • Auto Path Finding
  • Autonomy Engine collects surrounding environmental data and plans 3D flight paths through complex environments such as mountains, forests, and buildings. Use cases include rapid 3D scene reconstruction, public safety overwatch, industrial inspection, and land surveying.;
  • Navigation in GPS Denied Environment
  • Advanced sensors allow the MR-Max series to navigate within hardened structures, underground, or in environments without GPS.
  • Accurate Object Identification and Tracking;
  • Based on Autel's AI recognition technology, the MR-Max series can automatically identify and lock onto different types of targets such as heat sources, moving people, or vehicles and achieve high-altitude tracking and data collection for law enforcement.;
  • Ultimate Obstacle Avoidance
  • The MR-Max series is the only commercial drone that combines traditional binocular vision systems with millimeter wave radar technology. This allows the onboard Autel Autonomy Engine to perceive objects down to 0.5 inches, eliminating blind spots and enabling operation in low light or rainy conditions.;
  • Anti Jam, Anti Interference
  • The MR-Max series uses advanced flight control modules and algorithms specially designed to counter RFI, EMI, and GPS spoofing. This enables MR-Max series to fly confidently near power lines, critical structures, and in complex areas.
  • The Industry's First Mesh Networking
  • The MR-Max series features the new A-Mesh system, enabling drone-to-drone autonomous communication, connection, and collaboration
  • Enhanced Range
  • Communication nodes can be placed statically on hills or poles to provide full coverage to an area, or a swarm of drones can provide mobile communication points to extend the coverage of the entire group.
  • Beyond-Line-of-Sight Applications
  • With A-Mesh, multiple drones in the vicinity can act as relay points to greatly improve BVLOS operation effectiveness.
  • Enhanced Anti-Interference
  • The MR-Max series can communicate seamlessly with other drones in the vicinity, unlike a traditional chain structure. If a single drone fails or exits unexpectedly, the entire system will independently self-organize and continue to relay critical information.
  • Full-Fleet Control
  • Multiple drones can be controlled autonomously by 1 pilot or by a group of pilots simultaneously with or without LTE coverage.



Specifications :

Aircraft
Weight MR-Max 4T 1620g;MR-Max 4N 1641g
Dimensions 562*651*147 (folded, incl. propellers) 318*400*147(folded, excl. propellers) 257*145*131 (unfolded, excl. propellers)
Diagonal Wheelbase 466mm
Max Horizontal Speed (windless near sea level) 23m/s
Max Flight Time (windless) 42 mins
IP Rating IP43
Operating Temperature -4°F to 122°F (-20℃ - 50℃)
Hovering Accuracy

Vertical: ±0.1 m (Vision System enabled); ±0.5 m (GPS enabled);

Horizontal: ±0.3 m (Vision System enabled); ±0.5 m (GPS enabled);

Gimbal
Mechanical Range Pan: -135° to 45° Tilt: -45° to 45° Roll: -100° to 100°
Controllable Range -90° to 30°
Stable system 3-axis mechanical gimbal (pitch, tilt, roll)
Max Control Speed (pitch) 200º/s
Angular Vibration Range <0.005°
Wide Camera
Sensor 1/1.28 CMOS, Effective pixels: 50M
Lens DFOV: 85° Focal length: 4.5 mm (equivalent: 23 mm) Aperture: f/1.9
ISO Range

Auto:

Photo: ISO100~ISO6400

Video: ISO100~ISO64000 (Night scene mode: up to ISO64000)

Manual:

Photo: ISO100~ISO12800

Video: ISO100~ISO6400

MR-Max 4T Thermal Camera
Thermal Imager Uncooled VOx Microbolometer
Lens DFOV:42°
Aperture: 13mm
Focus: f/1.2
Infrared Temperature Measurement
Accuracy
±3℃ or reading ±3% (using
the larger value) @ambient
temperature -4℉ to 140℉
Video Resolution 640*512@25FPS
Pixel Pitch 12 um
Temperature Measurement Method Center measurement, pot measurement, rectangular measurement
Temperature Measurement Range -4℉ to 302℉, 32℉ to 1022℉ (-20°C to
150°C, 0 to 550°C)
Temperature Alert High and low temperature alarm thresholds, reporting coordinates and temperaturevalues
MR-Max 4N Thermal Camera
Thermal Imager Uncooled VOx Microbolometer
Lens DFOV: 61°
Aperture: 9.1mm
Focus: f/1.0
Infrared Temperature Measurement
Accuracy
±3℃ or reading ±3% (using
the larger value) @ambient
temperature -4℉ to 140℉
Video Resolution 640*512
Pixel Pitch 12 um
Temperature Measurement Method Center measurement, pot measurement, rectangular measurement
Temperature Measurement Range -4℉ to 302℉, 32℉ to 1022℉ (-20°C to
150°C, 0 to 550°C)
Temperature Alert High and low temperature alarm thresholds, reporting coordinates and temperaturevalues

Laser Range Finder
Measurement Accuracy ±1m
Measuring Range 1.2km
Image Transmission

Operating Frequency 2.4G/5.2G*/5.8G/900MHz*
Max Transmission Distance (unobstructed, free of interference)

20km(FCC)

8km(CE)

Transmitter Power (EIRP)

2.4GHz:<30dBm(FCC),

<20dBm(CE/SRRC/MIC)

5.8GHz:<27dBm(FCC), <30dBm(SRRC), <14dBm(CE)

5.15-5.25GHz: <23dBm(FCC/CE)

902-928MHz :<30dBm (FCC)

5.65-5.755GHz: MIC: <27dBm

Millimeter-wave Radar
Frequency 60Ghz/24Ghz
Range of perception

60GHz radar: upper: 0.3~20m, lower: 0.15~80m

Front and rear: 0.3~50m

24GHz radar: Below: 0.8~12m

FOV

Level (6dB) : ±60°/±22° (60GHz/24GHz)

Vertical (6dB) : ±30°/±20° (60GHz/24GHz)

Visual Sensing System
Obstacle Sensing Range

Before: 0.5~31m, after: 0.5~25m

Around: 0.5~26m, up: 0.2~26m

Lower: 0.3~23m

FOV

Front and rear: horizontal 60°, vertical 80°

Up and down: left and right 180°, front and back 120°

MR-Max 4N Night Vision Camera
Image Sensor Effective pixel 2.3 million
Lens

35mm equivalent focal length: 41.4mm

FOV: 52°

Zoom range: 1~8 times, support linkage zoom

ISO

Automatic mode:

ISO100~ISO450000

Night vision supersensitive:

Automatic ISO100~ISO450000

MR-Max 4T Zoom Camera

Image Sensor 1/2" CMOS with 48 million effective pixels
Lens

Focal length: 11.8-43.3mm(35mm equivalent focal length: 64-234mm)

Aperture: f/2.8-f/4.8

ISO

Normal mode:

Automatic: ISO100 to ISO6400

Manual:

Photograph: ISO100 to ISO12800

Video: ISO100 ~ ISO6400

Aircraft Battery
Capacity 8070mAh
Voltage 14.88V
Battery Type LiPo 4S
Energy 120wh
Net Weight 520g
Charging Temperature 5ºC to 45ºC(When the temperature is lower than 10° C (50° F), the selfheating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
Hot Swap Support
