Product Details
Place of Origin: China
Brand Name: Forward
Model Number: MR-Falcon 4T
Payment & Shipping Terms
Minimum Order Quantity: 1 PACK
Packaging Details: Standard Packaging
Payment Terms: L/C, T/T
Supply Ability: 100 pcs/years
Takeoff Weight: |
1600 G |
Dimensions: |
576*660*149 (folded, Incl. Propellers) 340*407*148(folded, Excl. Propellers) 257*136*133 (unfolded, Excl. Propellers) |
Wheelbase: |
464mm |
Max Ascent Speed/strong>: |
8m/s |
Max Level Flight Speed: |
6m/s |
Max Takeoff Altitude: |
7000m |
Max Flight Time (no Wind): |
42min |
Operating Temperature: |
-4°F To 122°F (-20℃ - 50℃) |
Takeoff Weight: |
1600 G |
Dimensions: |
576*660*149 (folded, Incl. Propellers) 340*407*148(folded, Excl. Propellers) 257*136*133 (unfolded, Excl. Propellers) |
Wheelbase: |
464mm |
Max Ascent Speed/strong>: |
8m/s |
Max Level Flight Speed: |
6m/s |
Max Takeoff Altitude: |
7000m |
Max Flight Time (no Wind): |
42min |
Operating Temperature: |
-4°F To 122°F (-20℃ - 50℃) |
The MR-Falcon 4T brings powerful technologies and advanced autonomy to users. MR-Falcon 4T assesses complex environments to create real-time 3D flight paths for unparalleled obstacle avoidance.Advanced sensors make flight in GPS unavailable areas possible and the incredible new thermal payload unlocks new object identification and tracking scenarios.With a foldable, weather-resistant design, the MR-Falcon 4T is as portable as it is capable.
.
Feature of MR-Falcon 4T Multi Rotor Industry UAV Drone Shouting Delivery Security Lighting Rescue Multi-functional UAV Drone :
Specifications MR-Falcon 4T Multi Rotor MR-Falcon 4T Multi Rotor Industry UAV Drone Shouting Delivery Security Lighting Rescue Multi-functional UAV Drone :
| Aircraft | ||||||||||||
| Weight | 3.5 lbs (1600g, battery and gimbal included) | |||||||||||
| Dimensions | 576*660*149 (folded, incl. propellers) 340*407*148(folded, excl. propellers) 257*136*133 (unfolded, excl. propellers) | |||||||||||
| Diagonal Wheelbase | 1.52 ft (464mm) | |||||||||||
| Max Ascent Speed | 8m/s | |||||||||||
| Max Descent Speed | 6m/s | |||||||||||
| Max Horizontal Speed (windless near sea level) | 22m/s | |||||||||||
| Max Service Ceiling Above Sea Level | 23000ft (7000m) | |||||||||||
| Max Flight Time (windless) | 42 mins | |||||||||||
| Max Hovering Time (windless) | 40 mins | |||||||||||
| Max Wind Resistance | 27mph* *Takeoff and landing can withstand wind speeds up to 27 mph (12 m/s). | |||||||||||
| IP Rating | IP43 | |||||||||||
| Max Tilt Angle | 35° | |||||||||||
| Max Angular Velocity | Pitch: 300°/s; Yaw: 120°/s | |||||||||||
| Operating Temperature | -4°F to 122°F (-20℃ - 50℃) | |||||||||||
| Operating Frequency | 2.4G/5.2G*/5.8G/900MHz* | |||||||||||
| Transmitter Power (EIRP) | 2.4GHz:<33dBm(FCC), 20dBm(CE/SRRC/MIC) 5.8GHz:33dBm(FCC), <30dBm(SRRC), <14dBm(CE) 5.15-5.25GHz: < 23dBm(FCC/SRRC/MIC) 5.25-5.35GHz:<30dBm(FCC), <23dBm(SRRC/MIC) | |||||||||||
| Hovering Accuracy | Vertical: ±0.1 m (Vision System enabled); ±0.3 m (GPS enabled); ±0.15 m (RTK enabled); Horizontal: ±0.15 m (Vision System enabled); ±0.3 m (GPS enabled); | |||||||||||
| Gimbal | ||||||||||||
| Mechanical Range | Pan: -135° to 45° Tilt: -45° to 45° Roll: -100° to 100° | |||||||||||
| Controllable Range | -90° to 45° | |||||||||||
| Stable system | 3-axis mechanical gimbal (pitch, tilt, roll) | |||||||||||
| Max Control Speed (pitch) | 200º/s | |||||||||||
| Angular Vibration Range | <0.005° | |||||||||||
| Zoom Camera (Telephoto) | ||||||||||||
| Sensor | 1/2" CMOS, Effective pixels: 48M | |||||||||||
| Lens | Focal length: 11.8-43.3mm (35mm, equivalent: 64-234mm) Aperture: f/2.8-f/4.8 | |||||||||||
| Exposure Compensation | ±3EV 0.3EV/step | |||||||||||
| ISO Range | Normal Mode: Auto: ISO100 ~ ISO6400 Manual: Photo: ISO100 ~ ISO12800 Video: ISO100 ~ ISO6400 | |||||||||||
| Shutter Speed | Photo: 8s ~ 1/8000s Video: 1s ~ 1/8000s | |||||||||||
| Max Photo Size | 8000×6000 | |||||||||||
| Max Video Resolution | 7680×4320 | |||||||||||
| Wide Camera | ||||||||||||
| Sensor | 1/1.28 CMOS, Effective pixels: 50M | |||||||||||
| Lens | DFOV: 85° Focal length: 4.5 mm (equivalent: 23 mm) Aperture: f/1.9 AF motor: 8-wire SMA, PDAF focus | |||||||||||
| Exposure Compensation | ±3EV 0.3EV/step | |||||||||||
| ISO Range | Auto: Photo: ISO100~ISO6400 Video: ISO100~ISO64000 (Night scene mode: up to ISO64000) Manual: Photo: ISO100~ISO12800 Video: ISO100~ISO6400 | |||||||||||
| Shutter Speed | Photo: 8s ~ 1/8000s Video: 1s ~ 1/8000s | |||||||||||
| Max. Video Resolution | 3840×2160 | |||||||||||
| Photo Size | 8192*6144 4096*3072 | |||||||||||
| Thermal Camera | ||||||||||||
| Thermal Imager | Uncooled VOx Microbolometer | |||||||||||
| Lens | DFOV: 64° Aperture: 13mm Focus: f/1.2 |
|||||||||||
| Infrared Temperature Measurement Accuracy |
26.6~37.4 ℉ or reading ±3% (using the larger value) @ambient temperature -4℉ to 140℉ |
|||||||||||
| Video Resolution | 640*512 | |||||||||||
| Photo Size | 640*512 | |||||||||||
| Pixel Pitch | 12 um | |||||||||||
| Temperature Measurement Method | Center measurement, pot measurement, rectangular measurement | |||||||||||
| Temperature Measurement Range | -4℉ to 302℉, 32℉ to 1022℉ (-20°C to 150°C, 0 to 550°C) |
|||||||||||
| Temperature Alert | High and low temperature alarm thresholds, reporting coordinates and temperaturevalues | |||||||||||
| Laser Range Finder | ||||||||||||
| Measurement Accuracy | ±1m | |||||||||||
| Measuring Range | 1.2km | |||||||||||
| Image Transmission | ||||||||||||
| Operating Frequency | 2.4G/5.2G*/5.8G/900MHz* | |||||||||||
| Max Transmission Distance (unobstructed, free of interference) | 20km | |||||||||||
| Independent Networking | 7.9-inch Smart Controller | |||||||||||
| Transmitter Power (EIRP) | 2.4GHz:<33dBm(FCC), <20dBm(CE/SRRC/MIC) 5.8GHz:<33dBm(FCC), <30dBm(SRRC), <14dBm(CE) 5.15-5.25GHz: <23dBm(FCC/SRRC/MIC) | |||||||||||
| Autonomy | ||||||||||||
| Non-GPS Hovering and Manual Flight | Indoor: Horizontal error ≤3cm (At least have texture at one direction) Outdoor: Daytime: Within 500m flight height, horizontal error < 0.01*height Night: Manual flight is controllable within 100m flight height | |||||||||||
| Non-GPS Return-to-Home | Within 500m flight height, horizontal error of Return-to-Home point < 30cm | |||||||||||
| Automatic Obstacle Rerouting | High Speed Obstacle Rerouting: Flight speed up to 20m/s when Min. safety distance to obstacle is 1.5m High Precision Obstacle Rerouting: Flight speed could reach 3m/s when Min. safety distance to obstacle is 0.2m | |||||||||||
| Multi-target Recognition and Tracking | Target identification types: people, vehicles, boats Number of targets detected: 64 Comprehensive recognition accuracy: > 85% | |||||||||||
| Millimeter-wave Radar | ||||||||||||
| Frequency | 60Ghz~64Ghz | |||||||||||
| Size | 38*14*2mm | |||||||||||
| Weight | 2g | |||||||||||
| EIRP | 18dbm | |||||||||||
| Distance Detection Range | For Obstacle Avoidance:0.2m~100m For Height Measurement:0.05m~200m | |||||||||||
| Ranging Accuracy | For Obstacle Avoidance:0.1m For Height Measurement:0.02m | |||||||||||
| Speed Measurement Range | ± 60m/s(4D Mode)；±28m/s(3D Mode)； | |||||||||||
| Speed Measurement Accuracy | ≤1% | |||||||||||
| Max. Tracking Target Number | 32 | |||||||||||
| Visual Sensing System | ||||||||||||
| Obstacle Sensing Range | Forward/Upward/Downward/Backward/Sideward: 0.2~50m | |||||||||||
| FOV | Forward/Backward/Sideward: 60°(H),80°(V) Upward/Downward: 360°(H),190°(V) | |||||||||||
| 7.9-inch smart controller | ||||||||||||
| Screen | 7.9 inch, 2000nits max. brightness, 2048*1536 resolution | |||||||||||
| External Battery | Capacity: 5800mAh Voltage: 11.55V Battery Type: Li-on Energy: 67Wh Charing time: 120mins Intelligent Lithium Ion Battery | |||||||||||
| Operating Time | 3 hours (Max. brightness) 4.5 hours (50% brightness) | |||||||||||
| Max Transmission Distance (with interference) | FCC: 20km CE: 7km | |||||||||||
| Storage | 128G | |||||||||||
| GNSS | GPS+GLONASS+Galileo+Beidou | |||||||||||
| Operating Temperature | -20℃ to 40℃ | |||||||||||
| Protocol | WiFi Direct, Wi-Fi Display, 802.11a/b/g/n/ac Support 2 x 2 MIMO Wi-Fi | |||||||||||
| Operating Frequency | 2.400 - 2.4835 GHz； 5.150 - 5.250GHz； 5.725 ‒ 5.850 GHz | |||||||||||
| Transmitter Power (EIRP) | 2.400 - 2.4835 GHz FCC/CE:≤20dBm 5.150 - 5.250GHz FCC:≤17dBm 5.725 ‒ 5.850 GHz FCC:≤17dBm CE:≤14dBm | |||||||||||
| Aircraft Battery | ||||||||||||
| Capacity | 8070mAh | |||||||||||
| Voltage | 14.88V | |||||||||||
| Battery Type | LiPo 4S | |||||||||||
| Energy | 120wh | |||||||||||
| Net Weight | 520g | |||||||||||
| Charging Temperature | 5ºC to 45ºC(When the temperature is lower than 10° C (50° F), the selfheating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery) | |||||||||||
| Hot Swap | Support | |||||||||||
